Heater coil replacement is one of those important services you have to do if the windshield fogs when the defroster is running. Another visible sign of trouble is damp carpeting, usually on the passenger side of the vehicle near where the heater core is located. When working properly, the heater coil sends heat to the cabin. When it leaks, it must be replaced! Getting the job done ranges from easy to difficult, depending on the core’s location inside your car. Your time is valuable to us, so when you need prompt and reliable heater core replacement service, book a Wrench mobile mechanic for your convenience. We’ll send you a quote when you know what work needs to be done, and if you aren’t sure what you need, we’ll come to you to perform diagnostic tests when you book a mobile mechanic.

What is Heater Coil Replacement?

A heater coil is a small radiator that receives hot coolant from the top of your engine. You engine’s water pump circulates coolant from the main radiator into the engine and forces a portion of that hot coolant into the heater core. The hot coolant flows through the heater coil and returns to the water pump through a second heater hose. With your blower fan operating, the heater coil can add 85° to 100° above outside temperatures, giving you’re a maximum cabin temperature of up to 90°F.

How is Heater Coil Replacement Done?

1. Disconnect the vehicle battery and remove the steering wheel.
2. Remove all outer doors and casings from the kick panels, fuse box, and speakers.
3. Remove any gauges, radio, speakers, glove box, and any other accessories.
4. Detach your air conditioner control panel.
5. Unbolt and carefully remove the car dashboard.
6. Identify and disconnect the 2 heater hoses.
7. Shift air ducts and other components away from the casing/housing of the heater.
8. Finally remove the heater coil from its casing/housing.
9. Remove any fasteners or screws to gain free access to the heater coil itself. Take the old heater coil out and simply insert and fasten the replacement.

Recommendations

Besides not functioning in the way intended, a leaking heater coil creates a mess. The liquid is coolant, also known as antifreeze, and it can damage your car. Antifreeze is also toxic and if somehow ingested, it can make a person very ill. Ethylene glycol, methanol and propylene glycol are among the main ingredients present and may lead to serious symptoms if not immediately treated.

Symptoms That Indicate You Need A Heater Coil Replacement

• Little or no heat inside car
• Coolant level is dropping, or your engine is running hot.
• You see signs of a coolant leak under the dashboard
• Windows fog up

The heater coil may not be critical to the function and running of your car while on the road. However, it has a vital role when it comes to making your driving experience comfortable.
